Fujitsu PRIMERGY RX1330 M5 User Manual

Figure 139: Full height riser module
9.5.2 Installing an expansion card
Upgrade and Repair Unit
(URU)
Hardware: 10 minutes
Software: 5 minutes
Tools: tool-less
Preliminary steps
▶
"Suspending BitLocker functionality" on page 69
.
▶
If applicable, "Removing the front cover with lock" on page 45.
▶
"Shutting down the server" on page 46.
▶
"Disconnecting the power cord" on page 47.
▶
"Getting access to the component" on page 49.
▶
Remove the corresponding riser module, see "Removing a riser module" on
page 63.
Expansion cards and backup units
RX1330 M5 Upgrade and Maintenance Manual 195

Fujitsu PRIMERGY RX1330 M5 Specifications

General

Processor Sockets	1
Memory	Up to 128 GB
Memory Type	DDR4
Form Factor	1U rack server
Memory Slots	4 DIMM slots
Storage	Up to 4x 3.5" or 8x 2.5" drives
RAID Support	RAID 0, 1, 5, 6, 10, 50, 60
Network	2x 1GbE LAN ports
Power Supply	800W
