Removing the defective 3.5-inch HDD module
▶
Remove the HDD module, see "Removing a 3.5-inch HDD module" on
page 130.
▶
If applicable, remove the HDD from the installation frame, see "Handling
HDDs or SSDs without installation frame" on page 121.
Installing the new 3.5-inch HDD module
▶
If applicable, install the HDD in the installation frame, see "Handling HDDs
or SSDs without installation frame" on page
121.
▶
Install the HDD module, see "Installing a 3.5-inch HDD module" on
page 128.
Concluding steps
▶
If applicable, "Installing the front cover with lock" on page 61.
▶
If the HDD is configured using a RAID controller with a RAID level higher
than "0", the rebuild will start automatically, see "Performing a RAID array
rebuild" on page 87.
7.4.5 Replacing the 4x 3.5-inch HDD backplane
Field Replaceable Unit
(FRU)
Hardware: 10 minutes
Tools: tool-less
Preliminary steps
▶
"Locating the defective server" on page 43
.
▶
If applicable, "Removing the front cover with lock" on page 45.
▶
"Shutting down the server" on page 46.
▶
"Disconnecting the power cord" on page 47.
▶
"Getting access to the component" on page 49.
Hard disk drive (HDD) / solid state disk (SSD)
RX1330 M5 Upgrade and Maintenance Manual 133
