Figure 156: Position and bolts of the FBU (RX1330 M5S)
9.6.2 Installing an FBU
Upgrade and Repair Unit
(URU)
Hardware: 15 minutes
Tools: tool-less
Preliminary steps
▶
If applicable, "Removing the front cover with lock" on page
45
.
▶
"Shutting down the server" on page 46.
▶
"Disconnecting the power cord" on page 47.
▶
"Getting access to the component" on page 49.
Expansion cards and backup units
RX1330 M5 Upgrade and Maintenance Manual 211
