Fujitsu PRIMERGY RX1330 M5 User Manual

15.6.4 Replacing an M.2 SSD
Upgrade and Repair Unit
(URU)
Hardware: 5 minutes
Software: 15 minutes
Tools: tool-less
Preliminary steps
▶
"Locating the defective server" on page 43
.
▶
If applicable, "Removing the front cover with lock" on page 45.
▶
"Shutting down the server" on page 46.
▶
"Disconnecting the power cord" on page 47.
▶
"Getting access to the component" on page 49.
▶
Remove the riser module 2 and riser module 3, see "Removing a riser
module" on page 63.
Replacing the M.2 SSD
▶
Remove the defective M.2 SSD, see "Removing the M.2 SSD" on page 317.
▶
Install the new M.2 SSD, see "Installing the M.2 SSD" on page 313.
Concluding steps
▶
Install the riser module 2 and riser module 3, see "Installing a riser module"
on page 64.
▶
"Reassembling" on page 53.
▶
"Connecting the power cord" on page 57.
▶
"Switching on the server" on page 60.
▶
If applicable, "Installing the front cover with lock" on page 61.
System board and components
318 Upgrade and Maintenance Manual RX1330 M5

Fujitsu PRIMERGY RX1330 M5 Specifications

General

Processor Sockets	1
Memory	Up to 128 GB
Memory Type	DDR4
Form Factor	1U rack server
Memory Slots	4 DIMM slots
Storage	Up to 4x 3.5" or 8x 2.5" drives
RAID Support	RAID 0, 1, 5, 6, 10, 50, 60
Network	2x 1GbE LAN ports
Power Supply	800W
