Installing the M.2 SSD
CAUTION
An M.2 SSD in M.2 SSD2 is not recognized, if M.2 SSD1 is free.
▶
Install the M.2 SSD1 first.
To support different length of M.2 SSD, the M.2 SSD lock can be moved
to another position.
A
▶
If applicable, move the M.2 SSD lock to a fitting position:
▶
Open the M.2 SSD lock (1).
▶
Pull out the M.2 SSD lock (2).
▶
Insert the M.2 SSD lock in the second hole (3).
The M.2 SSD lock has a pin (A) to ensure right insertion.
▶
If applicable, close the M.2 SSD lock (4).
System board and components
RX1330 M5 Upgrade and Maintenance Manual 313
