Figure 166: Removing the FBU from the holder
▶
Pull the FBU at a slight angle out of the holder.
Concluding steps
▶
"Reassembling" on page
53.
▶
"Connecting the power cord" on page 57.
▶
"Switching on the server" on page 60.
▶
If applicable, "Installing the front cover with lock" on page 61.
9.6.4 Replacing an FBU
Upgrade and Repair Unit
(URU)
Hardware: 15 minutes
Tools: tool-less
Expansion cards and backup units
RX1330 M5 Upgrade and Maintenance Manual 219
