Enabling the boot watchdog in the BIOS
▶
Enter the BIOS.
▶
Select the Server Mgmt menu.
▶
Under Boot W
atchdog set the
Action setting to Reset.
▶
Save your changes and exit the BIOS.
For more information on how to access the BIOS and modify settings,
see the corresponding BIOS Setup Utility reference manual.
Enabling the boot watchdog using the iRMC S6 web interface
▶
Log in to the iRMC S6 web interface.
▶
Select the Settings menu.
▶
Open the Server Management page.
▶
In the Boot W
atchdog group, check the
Enable Boot Watchdog option.
The Enable Boot Watchdog option must be selected.
▶
Select Reset from the Watchdog Action list.
▶
Click Apply for the changes to take effect.
For more information on iRMC settings, see the iRMC user guides.
5.3.7 Enabling replaced components in the BIOS
When a CPU, an expansion card, or a memory module fails, the defective
component will be set to Disabled or Failed in the BIOS. The server will then
reboot with only the intact hardware components remaining in the system
configuration. After replacing the defective component, it needs to be
reenabled in the BIOS.
▶
Enter the BIOS.
▶
Select the Advanced menu.
Basic software procedures
RX1330 M5 Upgrade and Maintenance Manual 81

Fujitsu PRIMERGY RX1330 M5 Specifications

General

Processor Sockets	1
Memory	Up to 128 GB
Memory Type	DDR4
Form Factor	1U rack server
Memory Slots	4 DIMM slots
Storage	Up to 4x 3.5" or 8x 2.5" drives
RAID Support	RAID 0, 1, 5, 6, 10, 50, 60
Network	2x 1GbE LAN ports
Power Supply	800W
