Installing the FBU
Figure 157: Installing the FBU in the holder
▶
At a slight angle, fit the FBU under both retaining brackets of the holder.
▶
Push in the FBU until it locks in place.
Figure 158: Installing the FBU with the holder
Expansion cards and backup units
212 Upgrade and Maintenance Manual RX1330 M5
