Removing the slot cover
Figure 140: Removing the slot cover - example riser module 1
▶
Remove the slot cover.
CAUTION
▶
Keep the slot cover for future use.
▶
If the expansion card is removed and not replaced with a new
one, the slot cover must be reinstalled due to cooling, to comply
with applicable EMC regulations and to protect against fire.
Installing the expansion card
▶
Please read the documentation supplied with the expansion card.
▶
If applicable, install a slot bracket to the expansion card, see "Installing a
slot bracket" on page
183.
Figure 141: Installing an expansion card - example riser module 1
Expansion cards and backup units
196 Upgrade and Maintenance Manual RX1330 M5

Fujitsu PRIMERGY RX1330 M5 Specifications

General

Processor Sockets	1
Memory	Up to 128 GB
Memory Type	DDR4
Form Factor	1U rack server
Memory Slots	4 DIMM slots
Storage	Up to 4x 3.5" or 8x 2.5" drives
RAID Support	RAID 0, 1, 5, 6, 10, 50, 60
Network	2x 1GbE LAN ports
Power Supply	800W
