CAUTION
Depending on the configuration, different fan types are necessary!
â–¶
Please check, if you ordered the correct fans.
In the system information (Chassis ID EPROM) the terms "Singl Fan"
and "Dual Fan" are used in system names.
There is no difference for installing and removing procedures.
Figure 115: Numbering of single rotor fans (RX1330 M5)
1 Fan 1
2 Fan 2
3
Fan 3
4 Fan 4
5 Fan 5
Fans
172 Upgrade and Maintenance Manual RX1330 M5
