Fujitsu PRIMERGY RX1330 M5 User Manual

Figure 183: Position of the ODD bay - example 3.5-inch HDD configuration
Figure 184: Position of the ODD bay - example 2.5-inch HDD configuration
The installation bay of the ODD depends on the 2.5-inch or 3.5-inch
HDD configuration. The proceeding for installing/removing is almost the
same.
Accessible drives
244 Upgrade and Maintenance Manual RX1330 M5

Fujitsu PRIMERGY RX1330 M5 Specifications

General

Processor Sockets	1
Memory	Up to 128 GB
Memory Type	DDR4
Form Factor	1U rack server
Memory Slots	4 DIMM slots
Storage	Up to 4x 3.5" or 8x 2.5" drives
RAID Support	RAID 0, 1, 5, 6, 10, 50, 60
Network	2x 1GbE LAN ports
Power Supply	800W
