â–¶
Remove the riser module 2, see "Removing a riser module" on page 63
.
Installing the TPM
Figure 239: Position for the TPM spacer
Figure 240: Inserting the TPM spacer on the system board
â–¶
Insert the TPM spacer into the hole on the system board.
System board and components
296 Upgrade and Maintenance Manual RX1330 M5

Table of Contents

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Fujitsu PRIMERGY RX1330 M5 and is the answer not in the manual?

Fujitsu PRIMERGY RX1330 M5 Specifications

General IconGeneral
Processor Sockets1
MemoryUp to 128 GB
Memory TypeDDR4
Form Factor1U rack server
Memory Slots4 DIMM slots
StorageUp to 4x 3.5" or 8x 2.5" drives
RAID SupportRAID 0, 1, 5, 6, 10, 50, 60
Network2x 1GbE LAN ports
Power Supply800W
