Preliminary steps
If applicable, "Removing the front cover with lock" on page 45
.
"Shutting down the server" on page 46.
"Disconnecting the power cord" on page 47.
"Getting access to the component" on page 49.
"Removing the air duct" on page 65.
If appicable,remove the riser module 1, see "Removing a riser module" on
page 63.
Removing the iRMC microSD card
Figure 247: Removing the iRMC microSD card
To eject the iRMC microSD card, gently push it in and then let go (1).
Pull the iRMC microSD card straight out of its slot (2).
CAUTION
(not valid for Europe, Middle East, India and Africa)
The iRMC microSD card contains customer information.
After removing the iRMC microSD card, hand the card over to
the customer.
If the customer requests disposal of the defective microSD card,
proceed as follows: Using a pair of side-cutting pliers, cut the
microSD card in half.
System board and components
308 Upgrade and Maintenance Manual RX1330 M5
