Pos. Print Description
4 PWR2 Power connector
5 PC98 Power connector
6 PWR1 Power connector
7 ODD PWR Power connector for ODD
8 FAN5 SYS Power connector for system fan 5
9 FAN6 SYS Power connector for system fan 6
10 FAN4 SYS Power connector for system fan 4
11 FAN3 SYS Power connector for system fan 3
12 TPM Connector for optional TPM
13 USB 5 Connector for Dual microSD 64GB Enterprise
14 FAN2 SYS Power connector for system fan 2
15 SMBSYS Connector for OBB cable
16 FAN1 SYS Power connector for system fan 1
17 Front VGA Connector for optional front VGA
18 ROC Connector for Dual microSD 64GB Enterprise
cable
19 SATA ODD SATA connector for ODD
20 Micro SD iRMC microSD card
21 SATA 0-3 SATA HDD connector
22 HDD LED Connector for HDD LED cable (e.g. PRAID
EP5xxi)
23 M.2 SSD2 M.2 slot 2
24 M.2 SSD1 M.2 slot 1
25 SERIAL Connector for optional serial interface
Appendix A
344 Upgrade and Maintenance Manual RX1330 M5

Fujitsu PRIMERGY RX1330 M5 Specifications

General

Processor Sockets	1
Memory	Up to 128 GB
Memory Type	DDR4
Form Factor	1U rack server
Memory Slots	4 DIMM slots
Storage	Up to 4x 3.5" or 8x 2.5" drives
RAID Support	RAID 0, 1, 5, 6, 10, 50, 60
Network	2x 1GbE LAN ports
Power Supply	800W
