The requirements are:
–
iRMC S6 Firmware
–
supported OOB RAID system
16.2.2.3 Indicator on the ODD
ODDs may have an indicator or not.
Figure 277: Indicator on the ODD (example)
1 Activity indicator
Activity indicator (1)
Status Description
off The ODD is inactive.
green on The storage medium is being accessed.
Appendix A
352 Upgrade and Maintenance Manual RX1330 M5
