Fujitsu PRIMERGY RX1330 M5 User Manual

The latest BIOS and iRMC versions are available from the Fujitsu support
internet pages at:
https://ts.fujitsu.com/support/
For Japan:
https://www.fujitsu.com/jp/products/computing/servers/primergy/downloads/
Note on the boot watchdog
Before updating or recovering the BIOS and iRMC, ensure that the boot
watchdog is disabled, see "Disabling the boot watchdog" on page 70.
After updating or recovering the BIOS and iRMC, enable the boot
watchdog again, see "Enabling the boot watchdog" on page 80.
Fujitsu does not assume responsibility for any damage done to the
server or for the loss of any data resulting from BIOS updates.
BIOS flash procedure
▶
Perform the BIOS flash procedure as described in the "BIOS Setup Utility"
reference manual of your server.
BIOS recovery procedure
▶
Perform the BIOS recovery procedure as described in the "BIOS Setup
Utility" reference manual of your server
.
iRMC flash procedure
▶
Prepare an USB stick including the bootable iRMC firmware update image.
▶
Connect the USB stick containing the iRMC firmware to an USB port.
▶
Restart the server. The system will start the POST process.
▶
During POST, press [F12] and select the connected USB stick as boot
device. The system will detect the USB stick.
Basic software procedures
74 Upgrade and Maintenance Manual RX1330 M5

Fujitsu PRIMERGY RX1330 M5 Specifications

General

Processor Sockets	1
Memory	Up to 128 GB
Memory Type	DDR4
Form Factor	1U rack server
Memory Slots	4 DIMM slots
Storage	Up to 4x 3.5" or 8x 2.5" drives
RAID Support	RAID 0, 1, 5, 6, 10, 50, 60
Network	2x 1GbE LAN ports
Power Supply	800W
