GAMATRONIC ELECTRONIC INDUSTRIES LTD.
86
POWER
+
PARALLEL
UPS,
USER GUIDE
,
REL
.
2.0
2. Select Module conf.:
[Main Menu > SETUP > (password) > Ent]
1> Alarm set 5> Time 9> Silicon
2> Module conf. 6> Site
3> Battery 7> Password #1
4> Charge 8> Service
Figure 140: Setup menu
7.9.1 Setting Number of Phases
1. Select Num of phase:
[Main Menu > SETUP > (password) > Module conf.]
1. Num of phase 5.Output Adjust
2. Module/s frequency 6.Frequency Limits
3. Module/s voltage 7.DC Calibration
4. Update Vo/Fr/ph 8.AC Calibration
Figure 141: Module Config. setup menu
7.9.2 Setting Module/s Frequency
1. Select Module/s frequency:
[Main Menu > SETUP > (password) > Module conf.]
1. Num of phase 5.Output Adjust
2. Module/s frequency 6.Frequency Limits
3. Module/s voltage 7.DC Calibration
4. Update Vo/Fr/ph 8.AC Calibration
Figure 142: Module Config. setup menu
2. Use the ▲▼arrow keys to set the module/s frequency, press Ent, and then Esc:
[Main Menu > SETUP > (password) > Module conf. > Module/s frequency]
--- SET MODULE/S FREQUENCY ---
SELECT – 1 HARD (DIP DEPEND.)
SELECT – 2 SET 50HZ (SELECTED)
SELECT – 3 SET 60HZ
Figure 143: Setting the Module/s frequency
