10. View status of the fuses:
[Main Menu > SYSTEM > ▼ ▼ ▼ ▼ ▼ ▼]
BATT FUSE: BAD EMERGENCY: OPEN
USER-1: OPEN USER-4: OPEN
USER-2: OPEN 7: OPEN
USER-3: OPEN 8: OPEN
Figure 92: Fuse status
11. View communication with the converter in the transmit mode (for Technicians):
[Main Menu > SYSTEM > ▼ ▼ ▼ ▼ ▼ ▼ ▼]
PD DIALOG: UPS #01
T>c0 42 00 00 d8 00 00 00 00 00 00 00 00
00 00 00 00 00 00 aa
Figure 93: Communication with inverter – transmit
12. View communication with the converter in the receive mode (for Technicians):
[Main Menu > SYSTEM > ▼ ▼ ▼ ▼ ▼ ▼ ▼ ►]
R<e0e0 0900 0003 0003 0003 e874 1074
1074 2f37 5362 0000 0200 0100 0310
f077 0000 0000 0000 0000 0000 0000
0000 0000 0000 0000 52 52
Figure 94: Communication with inverter – receive
13. Press Ent to return to the Main Menu (Figure 81 on page 61).
