Gamatronic Power+ - Figure 214: Setup Menu; Figure 215: Service Menu; Figure 216: Set Upss; Figure 217: Service Menu

GAMATRONIC ELECTRONIC INDUSTRIES LTD.
110
POWER
+
PARALLEL
UPS,
USER GUIDE
,
REL
.
2.0
2. Select Service:
[Main Menu > SETUP > (password) > Ent]
1> Alarm set 5> Time 9> Silicon
2> Module conf. 6> Site
3> Battery 7> Password #1
4> Charge 8> Service
Figure 214: Setup menu
7.12.1 Setting UPSs
1. Select UPSs:
[Main Menu > SETUP > (password) > Ent > Service]
1> ------ 4> DryOut Test 7> --------
2> UPSs 5> Configure 8> Powr.Calib
3> ------- 6> En/Dis shar 9> SC2012..
Select, then Enter
Figure 215: Service menu
2. Use the arrow keys to set UPSs, and press Esc when finished:
[Main Menu > SETUP > (password) > Ent > Service > UPSs]
1234
++++
SET UPSs (UP= ON<+>, DOWN= OFF<->)
Enter = Execute Esc= Go back
Figure 216: Set UPSs
7.12.2 Testing Dry Output Relays
1. Select DryOut Test:
[Main Menu > SETUP > (password) > Ent > Service]
1> ------ 4> DryOut Test 7> --------
2> UPSs 5> Configure 8> Powr.Calib
3> ------- 6> En/Dis shar 9> SC2012..
Select, then Enter
Figure 217: Service menu
