2. View the input and output voltage and current for each phase of a particular UPS module. Scroll
down ▼ to view other UPS modules.
[Main Menu > UPS MODULE > ▼]
PHASE: -L1-- -L2-- -L3—
IN: 000V/000.0A 000V/000.0A 000V/000.0A
OUT: 000V/000.0A 000V/000.0A 000V/000.0A
UPS:# 01/04
Figure 97: Module phase voltages/currents
3. View the battery voltage for the selected UPS module (the parameters
I-ACTIVE and I-BUS are for a technician only).
[Main Menu > UPS MODULE > ▼ > ►]
BATT VOLT I-ACTIVE I- BUS
BATT+: 216V L1 000 L1 000
BATT-: 216V L2 000 L2 000
UPS: #01/04 L3 000 L3 000
Figure 98: Battery voltages & technician parameters
