7.10.12 Activating ‘Auto’ Test
1. Select ‘AuTo’ Test:
[Main Menu > SETUP > (password) > Battery]
1> Test-Voltage 5> Battery test…
2> Test Alarm 6> Capacity 0020 AH)
3> Current-Limit.. 7> ‘AuTo’ Test
4> Temp Compensat. 8> Enable/Dis Options
Figure 196: Battery setup menu
2. The test is performed. Press Ent when done.
[Main Menu > SETUP > (password) > Battery > ‘Auto’ Test]
Max/estim time left : 00:00:00 /--:--:--
Battery test in progress for: 00:00:00
Batt. volt: 860.0V Batt.current: 008
Last test: PASSED Days left: 027
Figure 197: Activated ‘Auto’ test
7.10.13 Enabling/Disabling Options
1. Select Enable/Dis Options:
[Main Menu > SETUP > (password) > Battery]
1> Test-Voltage 5> Battery test…
2> Test Alarm 6> Capacity 0020 AH)
3> Current-Limit.. 7> ‘AuTo’ Test
4> Temp Compensat. 8> Enable/Dis Options
Figure 198: Battery setup menu
2. Select ENABLE SHUTDOWN by long AC FAIL (Off) and press Ent to toggle enable/disable:
[Main Menu > SETUP > (password) > Battery > Enable/Dis Options]
1> ENABLE SHUTDOWN by long AC FAIL (Off)
2> ENABLE Current Sensors (Off)
3> ENABLE BATT Temperature sensor (Off)
Select & Press To toggle Enable/Disable
1> DISABLE SHUTDOWN by long AC FAIL(On )
2> ENABLE Current Sensors (Off)
3> ENABLE BATT Temperature sensor (Off)
Select & Press To toggle Enable/Disable
Figure 199: Enable/Disable shutdown by long AC failure
