GAMATRONIC ELECTRONIC INDUSTRIES LTD.
92
1. To enter Setup, use the default password <<<<<<<< (left arrow key eight times).
[Main Menu > SETUP]
POWER+ System Setup
Type in Level-1 PASSWORD, THEN – ENTER
Your privilege will expire after 15 min.
PASSWORD:________
Figure 161: Level 1 password access
2. Select Battery:
[Main Menu > SETUP > (password) > Ent]
1> Alarm set 5> Time 9> Silicon
2> Module conf. 6> Site
3> Battery 7> Password #1
4> Charge 8> Service
Figure 162: Setup menu
7.10.1 Setting Battery Test Voltage
1. Select Test-Voltage:
[Main Menu > SETUP > (password) > Battery]
1> Test-Voltage 5> Battery test…
2> Test Alarm 6> Capacity 0020 AH)
3> Current-Limit.. 7> ‘AuTo’ Test
4> Temp Compensat. 8> Enable/Dis Options
Figure 163: Battery setup menu
2. Using the arrow keys, set the battery test voltage and press Ent:
[Main Menu > SETUP > (password) > Battery > Test Voltage]
BATTERY (test) VOLTAGE SETUP
VOLTAGE SETTING: 352.0V
Figure 164: Set battery test voltage
