GAMATRONIC ELECTRONIC INDUSTRIES LTD.
24
3.5 First-time Startup
Note: Before first setting up the UPS, make sure that the load is not connected.
When applying power to the POWER
+
, the system automatically runs the startup process without a
need to press the On/Off button.
1. Turn the ac input and ac bypass switch ON and wait (for about 2 minutes) for the POWER
+
to
initialize.
2. The start-up sequence will begin and the control panel will show the following sequence. (The
details of the display may vary from what is shown in the illustrations below, depending on your
system's particulars.)
At start-up, the following screen sequence appears:
UPS POWER+
SC25270105
W E L C O M E ! ! !
Figure 15: Start-up screen 1
WARNING !!!
SYSTEM RUNNING IN:
S I L I C O N M O D E (JP2 – IN)
--------PLEASE NOTIFY SUPERVISOR--------
Figure 16: Start-up screen 2
In “SILICON MODE”, commands issued through the Power+ Control Panel are executed
immediately. Operators should exercise caution.
Note: In Figure 16, “Silicon mode” indicates that the configuration jumper is installed, thus allowing for
modifications.
WAIT FOR RESULTS…
STATIC RAM: PASSED R.T CLOCK: PASSED
EEPROM – 1: PASSED
EEPROM – 3: PASSED DC SUPPLIES: PASSED
Figure 17: Start-up screen 3
S Y S T E M I N I T I A L I Z I N G
SC25270105
PLEASE WAIT FOR COUNT DOWN TO FINISH
45 SECONDS LEFT
Figure 18: Start-up screen 4
