7. POWER+ MENU FUNCTIONS IN DETAIL
This chapter describes the functions available through the POWER
+
Main Menu and its submenus.
Note: If you are viewing this file in PDF format, it is possible to search for text in the displayed screens. This eases
finding the desired screen.
7.1 Main Menu
Press the Enter button (Ent) to display the main menu.
Note: To return to the main menu at any time, press the Escape button (Esc) and then Ent.
1> SYSTEM 4> HISTORY 7> SETUP
2> UPS MODULE 5> BATTERY 8> STATIC SW
3> SELFTEST 6> ALARM 9> _____
NAVIGATE: <UP, DOWN> 1 SELECT: <ENTER>
Figure 81: Main menu
Table
8: Main Menu Options
1>
SYSTEM
General information such as voltages, currents etc.
2> UPS MODULE
Information for a specific UPS module
3> SELFTEST
Self checking of the Controller's components (supply, RTC, memory)
4>
HISTORY
History log events (last 255 events, dated and timed)
5> BATTERY
Charging / discharging voltages and currents, battery test etc.
6> ALARM
Detailed alarm status
7>
SETUP
Configuring the system (number of modules, alarm, time etc.)
8>
STATIC SW
Static Switch data
