Table 20: Specifications
TECHNICAL DATA FOR A SINGLE POWER
+
SYSTEM (PARALLEL MODEL)
Topology
On line battery, double conversion, VFI
Construction
Modular parallel hot-plugged modules
Operation
Continuous
Input
Voltage
3 × 400 Vac + N (3 x 230 Vac + Neutral)
Voltage range
– 27 % and + 20 %
Current
3 × 15 A per module – no inrush current at startup
Frequency
47-63 Hz
Power walk-in
> 60 sec.
Power Factor
0.99
THDI
5 %
Output
Rated Power
10 kVA / 8 kW per module
Frequency tracking range
±2 Hz
Slew rate
1 Hz/sec
Voltage
3 × 400 Vac + N (3 x 230 Vac + Neutral)
Static Regulation
±1 %
Regulation for unbalanced load
±1 for 100% unbalanced load
Dynamic response to 100% load step
±2 %
Overload
110% for 10 min., 125% for 60 sec., 1000% for 1 cycle
Waveform
Sinusoidal
THD
Less than 2 % for linear load
Load CF
6:1
AC-AC efficiency (nominal)
Up to 96 % at full load
DC-AC efficiency (nominal)
Up to 98 % at full load
Batteries
DC-Link Voltage
±340 to ±425 Vdc
Quantity
64 × 12 Vdc
Type
Sealed, lead acid, rechargeable
General
Max. power dissipation (Po=80 kW)
2664 W (9088 BTU) for 8 modules
Ambient temperature Operating:
Storage:
-10 to +40 °C (14 to 104 °F)
-20 to +60 °C (-4 to 140 °F)
Relative humidity
95 % max., non-condensing
Altitude
1500 m without derating
Enclosure
IP20
Cooling system
Multi-Fan with speed control (forced)
Standards
EMC
IEC 62040-2, under EMC 2004/108/EC
Design
IEC 62040-3
Safety
IEC 62040-1, under LVD 2006/95/EC
Low magnetic field radiation
EMF as per ICNIRP
Dimensions
UPS type
10
kVA
20
kVA
30
kVA
40
kVA
50
kVA
60
kVA
70
kVA
80
kVA
90
kVA
100
kVA
Height (cm)
71
80
90
99
108
118
127
136
146
155
Width (cm)
60
Depth (cm)
95
Weight
119
134
149
164
179
204
219
234
249
264
Acoustic Noise
Noise (dBA) with half load
48
52
53
54
55
55.8
56.4
57
57.5
58
Noise (dBA) with full load
51
54
55
57
58
58.8
59.4
60
60.5
61
All specifications are subject to change without notice.
Operation of the UPS in a parallel configuration may slightly alter the performance characteristics.
