Gamatronic Power+ - “Setup - Alarm Set” Option

GAMATRONIC ELECTRONIC INDUSTRIES LTD.
62
POWER
+
PARALLEL
UPS,
USER GUIDE
,
REL
.
2.0
7.2 “System” Option
Figure 82: Main menu option 1 ("System")
1. The SYSTEM option (option 1) shows the dc voltages and current (positive, negative and
summary):
[Main Menu > SYSTEM]
BATT CURR: -----> TOTAL +053.0A
BATT POS.: 430V BATT +053.2A (0531)
BATT NEG.: 441V
BATT VOLT: 871V
Figure 83: System dc voltages
