GAMATRONIC ELECTRONIC INDUSTRIES LTD.
53
5.2 POWER
+
shutdown (switching to bypass)
1. Switch the load OFF.
2. Press twice on the On/Off button.
3. Wait 2 minutes for the POWER
+
to shut down. The control screen will indicate UPS OK (OFF).
LOAD LEVEL ---22:21:18---
L1:__________ 000A, 230V BATTERY: 864V
L2:__________ 000A, 230V UPS OK (OFF)
L3:__________ 000A, 230V STSW OK (BYP)
Figure 65: Main screen – switching to bypass
Note: This does NOT switch the entire POWER
+
OFF. Power is still delivered to the load but in bypass.
Figure 66: Bypass indication
