UCM6200 Series User Manual
Serv or MPLS. Valid range is 0-63.
Assign the VLAN Tag of the Layer 2 QoS packets. Valid range is 0 -4095.
Layer 2 QoS Priority
Value
Assign the priority value of the Layer 2 QoS packets. Valid range is 0-7.
Configure the IP address or Domain name of the STUN server. Only non-
symmetric NAT routers work with STUN.
Specify how often the phone will send a blank UDP packet to the SIP server in
order to keep the "ping hole" on the NAT router to open. Valid range is 10-160.
Table 31: Global Policy Parameters->Customization
Screen Resolution 1024
x 600
Check this option if the SIP end device shall use 1024 x 600 resolution for the
LCD screen wallpaper.
• Source
Configure the location where wallpapers are stored.
• File
If "URL" is selected as source, specify the URL of the wallpaper file. If
"Local UCM Server" is selected as source, click to upload wallpaper file to
the UCM6200.
Screen Resolution 800 x
400
Check this option if the SIP end device shall use 800 x 400 resolution for the
LCD screen wallpaper.
• Source
Configure the location where wallpapers are stored.
• File
If "URL" is selected as source, specify the URL of the wallpaper file. If
"Local UCM Server" is selected as source, click to upload wallpaper file to
the UCM6200.
Screen Resolution 480 x
272
Check this option if the SIP end device shall use 480 x 272 resolution for the
LCD screen wallpaper.
• Source
Configure the location where wallpapers are stored.
• File
If "URL" is selected as source, specify the URL of the wallpaper file. If
"Local UCM Server" is selected as source, click to upload wallpaper file to
the UCM6200.
Screen Resolution 320 x
240
Check this option if the SIP end device supports 320 x 240 resolution for the
LCD screen wallpaper.
• Source
Configure the location where wallpapers are stored.
