UCM6200 Series User Manual
802.1X Client
Certificate
Select 802.1X client certificate from local PC and then upload.
Static Routes
The UCM6200 provides users static routing capability that allows the device to use manually configured routes,
rather than information only from dynamic routing or gateway configured in the UCM6200 web GUI->Network
Settings->Basic Settings to forward traffic. It can be used to define a route when no other routes are available
or necessary, or used in complementary with existing routing on the UCM6200 as a failover backup, and etc.
• Click on to create a new static route. The configuration parameters are listed in the
table below.
• Once added, users can select to edit the static route.
• Select to delete the static route.
Table 11: UCM6200 Network Settings->Static Routes
Configure the destination IP address or the destination IP subnet for the UCM6200
to reach using the static route.
Example:
IP address - 192.168.66.4
IP subnet - 192.168.66.0
Configure the subnet mask for the above destination address. If left blank, the
default value is 255.255.255.255.
Example:
255.255.255.0
Configure the gateway address so that the UCM6200 can reach the destination
via this gateway. Gateway address is optional.
Example:
192.168.40.5
Specify the network interface on the UCM6200 to reach the destination using the
static route.
LAN interface is eth0; WAN interface is eth1.
