manually. Please make sure one channel is connected to the
UCM6200 and in idle status before starting the detection. During the
detection, source channel will be used as caller and send the call to
the configured Destination Number. Users will then need follow the
prompts in web GUI to help finish the detection.
The default setting is "Auto Detect".
--------------------------------------------------------------------------------------------------------------------------------------------
Note:
• The PSTN detection process will keep the call up for about 1 minute.
• If "Semi-auto Detect' is used, please pick up the call only after informed from the web GUI prompt.
• Once the detection is successful, the detected parameters "Busy Tone", "Polarity Reversal" and "Current
Disconnect by PSTN" will be filled into the corresponding fields in the analog trunk configuration.
--------------------------------------------------------------------------------------------------------------------------------------------
VOIP Trunks
VoIP trunks can be configured in UCM6200 under Web GUI->PBX->Basic/Call Routes->VoIP Trunks. Once
created, the VoIP trunks will be listed with Provider Name, Type, Hostname/IP, Username and Options to
edit/detect the trunk.
• Click on "Create New SIP Trunk" or "Create New IAX Trunk" to add a new VoIP trunk.
• Click on to configure detailed parameters for the VoIP trunk.
• Click on to configure Direct Outward Dialing (DOD) for the SIP Trunk.
• Click on to start LDAP Sync.
• Click on to delete the VoIP trunk.
For VoIP trunk example, please refer to the document in the following link:
http://www.grandstream.com/sites/default/files/Resources/ucm_to_ucm_peer_guide.pdf
