Storage to External Device

Check this box to activate storage of the capture either on the USB

or SD Card.

Capture Filter

Enter the filter to obtain the specific types of traffic, such as (host,

src, dst, net, proto…).

Start

Click to start the trace.

Stop

Click to stop the trace.

Download

Click to download the trace if trace is stored locally.

The output result is in .pcap format. Therefore, users could specify the capture filter as used in general network

traffic capture tool (host, src, dst, net, protocol, port, port range) before starting capturing the trace.

IP Ping

Enter the target host in host name or IP address. Then press "Start" button. The output result will dynamically

display in the window below.

Figure 243: Ping

Traceroute

Enter the target host in host name or IP address. Then press "Start" button. The output result will dynamically

display in the window below.
