UCM6200 Series User Manual
Figure 29: UCM6200 Using 802.1X as Client
Figure 30: UCM6200 Using 802.1X EAP-MD5
The following table shows the configuration parameters for 802.1X on UCM6200. Identity and MD5 password
are required for authentication, which should be provided by the network administrator obtained from the
RADIUS server. If “EAP-TLS” or “EAP-PEAPv0/MSCHAPv2” is used as the 802.1X mode, users will also need
to upload 802.1X CA Certificate and 802.1X Client Certificate, which should be also generated from the RADIUS
server.
Table 10: UCM6200 Network Settings->802.1X
802.1X Mode
Select 802.1X mode. The default setting is "Disable". The supported 802.1X mode
are:
• EAP-MD5
• EAP-TLS
• EAP-PEAPv0/MSCHAPv2
Identity
Enter 802.1X mode identity information.
MD5 Password
Enter 802.1X mode MD5 password information.
802.1X Certificate
Select 802.1X certificate from local PC and then upload.
