Grandstream Networks UCM6206 User Manual

P a g e | 231
UCM6200 Series User Manual
The template variables are:
• ${CALLERIDNUM} : Caller ID Number
• ${CALLERIDNAME} : Caller ID Name
• ${RECEIVEEXTEN} : The extension to receive the Fax
• ${FAXPAGES} : Number of pages in the Fax
• ${VM_DATE} : The date and time when the Fax is received
• Click on to edit the Fax extension.
• Click on to delete the Fax extension.
Sample Configuration to Receive Fax from PSTN Line
The following instructions describe how to use the UCM6200 to receive Fax from PSTN line on the Fax machine
connected to the UCM6200 FXS port.
1. Connect Fax machine to the UCM6200 FXS port.
2. Connect PSTN line to the UCM6200 FXO port.
3. Go to web GUI->PBX->Analog Trunks page.
4. Create or edit the analog trunk for Fax as below.
Fax Mode: Make sure "Fax Mode" option is set to "None".
