Grandstream Networks UCM6206 User Manual

P a g e | 299
UCM6200 Series User Manual
Table 107: Extension Status
Status
Display extension number (including feature code). The color indicator has the
following definitions.
• Green: Free
• Blue: Ringing
• Yellow: In Use
• Grey: Unavailable
Extension
Display the extension number.
Name/Label
First name and last name of the extension.
Message
Display message status for the extension.
Example: 2/4/1
Description: There are 2 urgent messages, 4 messages in total and 1 message
that has been already read.
Type
Displays extension type.
• SIP User
• IAX User
• Analog User
• Ring Groups
• Voicemail Groups
Other operations are also available in extension status section:
• Click on "Extensions", the web page will redirect to extension configuration page which can also be
accessed via web GUI->PBX->Basic/Call Routes->Extensions.
• Click on to refresh the extension status.
• Click on one of the tabs to display
the corresponding extensions accordingly.
• Click on [ + ] to expand the status detail table.
• Click on [ - ] to hide the status detail table.
Queues
Users could see all the configured call queue status in this section. The following figure shows the call queue
6500 being in used.
