UCM6200 Series User Manual
• Inband: Send DTMF using inband audio. This requires 64 bit codec, i.e.,
PCMU and PCMA.
• Auto: Send DTMF using RFC2833 if offered. Otherwise, inband will be
used.
Enable Heartbeat
Detection
If enabled, the UCM6200 will regularly send SIP OPTIONS to the device to check
if the device is still online. The default setting is "No".
Heartbeat Frequency
When "Enable Heartbeat Detection" option is set to "Yes", configure the interval
(in seconds) of the SIP OPTIONS message sent to the device to check if the device
is still online. The default setting is 60 seconds.
Maximum Number of
Call Lines
The maximum number of concurrent calls using the trunk. The default settings 0,
which means no limit.
Fax Mode
Select Fax mode. The default setting is “None”.
• None: Disable Fax.
• Fax Detect: Fax signal from the user/trunk during the call can be detected and
the received Fax will be sent to the Email address configured for this
extension. If no Email address can be found for the user, the Fax will be sent
to the default Email address configured in Fax setting page under web UI-
>PBX->Internal Options->Fax/T.38.
SRTP
Enable SRTP for the VoIP trunk. The default setting is "No".
Sync LDAP Enable
If enabled, the local UCM6200 will automatically provide and update the local
LDAP contacts to the remote UCM6200 SIP peer trunk. In order to ensure
successful synchronization, the remote UCM6200 peer also needs to enable this
option on the SIP peer trunk. The default setting is "No".
Sync LDAP
Password
This is the password used for LDAP contact file encryption and decryption during
the LDAP sync process. The password must be the same on both UCM6200 peers
to ensure successful synchronization.
Sync LDAP Port
Configure the TCP port used LDAP sync feature between two peer UCM6200.
LDAP Outbound Rule
Specify an outbound rule for LDAP sync feature. The UCM6200 will automatically
modify the remote contacts by adding prefix parsed from this rule.
LDAP Dialed Prefix
Specify the prefix for LDAP sync feature. The UCM6200 will automatically modify
the remote contacts by adding this prefix.
CC Settings
Enable CC
If enabled, the system will automatically alert the user when a called party is
available, given that a previous call to that party failed for some reason.
CC Max Agents
Configure the maximum number of CCSS agents which may be allocated for this
channel. In other words, this number serves as the maximum number of CC
requests this channel is allowed to make. The minimum value is 1.
CC Max Monitors
Configure the maximum number of monitor structures which may be created for
this device. In other words, this number tells how many callers may request CC
