UCM6200 Series User Manual
LAN 1 / LAN 2 (when Method is set to "Dual")
If "Dual" is selected as "Method", users will need assign the default interface to be LAN 1
(mapped to UCM6202 WAN port) or LAN 2 (mapped to UCM6202 LAN port) and then
configure network settings for LAN 1/LAN 2. The default interface is LAN 2.
Select DHCP, Static IP, or PPPoE. The default setting is DHCP.
Enter the IP address for static IP settings. The default setting is 192.168.0.160.
Enter the subnet mask address for static IP settings. The default setting is 255.255.0.0.
Enter the gateway IP address for static IP settings when the port is assigned as default
interface. The default setting is 0.0.0.0.
Enter the DNS server 1 address for static IP settings. The default setting is 0.0.0.0.
Enter the DNS server 2 address for static IP settings.
Enter the user name to connect via PPPoE.
Enter the password to connect via PPPoE.
Layer 2 QoS
802.1Q/VLAN
Tag
Assign the VLAN tag of the layer 2 QoS packets for LAN port. The default value is 0.
Layer 2 QoS
802.1p Priority
Value
Assign the priority value of the layer 2 QoS packets for LAN port. The default value is 0.
WAN (when "Method" is set to "Route")
Select Auto or Static. The default setting is Auto
Enter the IP address for static IP settings.
Enter the Prefix length for static settings. Default is 64
Enter the DNS server 1 address for static settings.
Enter the DNS server 2 address for static settings.
LAN (when Method is set to "Route")
Select Disable, Auto or DHCPv6.
Disable: the DHCPv6 server is disabled.
Auto: Stateless address auto configuration using NDP protocol.
DHCPv6: Stateful address auto configuration using DHCPv6 protocol.
Enter DHCP prefix. (Default is 2001:db8:2:2::)
Enter the Prefix length for static settings. Default is 64
Enter the DNS server 1 address for static settings. Default is (2001:4860:4860::8888 )
Enter the DNS server 2 address for static settings. Default is (2001:4860:4860::8844 )
