Microlab
®
STAR Service Manual
6-29
Corrective Actions (continued)
• Just untighten the 8 fixing screws and push or pull the arm by the back to its
appropriate position and tighten the 8 fixing screws.
Note: Do not push or pull the Pipetting Arm from the Front to align in X-Direction so
as to avoid a shift which could prevent proper adjustment (Hysteresis).
• Verify the current position by running the Adjustment Program again and iterate
if necessary.
• After completion of Alignment, check distance between Pipetting Arm Positioning
Reader and the Magnetic Tape underneath the deck. Refer to section 7.6
Pipetting Arm X-Drive on page 7-23.
Attention: Ensure Reader is not touching Magnetic Tape. On the other hand, the
gap should not be too great.
