7-10
Replacement (continued)
• Do not bend any parts of Contact
Plate (sheet metal).
• "Tongues" of Contact Plate must
be as close as possible to
Replace. Carrier Stop (solid piece).
• Replace. Carrier Stop P/N 182118
(solid piece)
• Contact Plate P/N 173288
(sheet metal)
• Carrier Sensor board P/N 173833
• 3 Screws P/N 420010 holding
Carrier Sensor board on Replace.
Carrier Stop.
To Next Page
