Hamilton Microlab STAR - Page 96

Microlab
®
STAR Service Manual
6-12
Adjustment Macro Programs (continued)
This List follows the order of Adjustment and Calibration
File Name Description
INSTRUMENT CHECK.MCR With Channel Calibration Tool
173960.
checks all calibration values of
Pipetting Arm, Channels and Heads.
Measurement Macro Program.
ARM Z-DIFFERENCE.MCR With Channel Calibration Tool
173960.
checks Z parallelity of Pipetting Arm
to Deck in functional dependence on
X- and Y-Axis.
Measurement Macro Program.
ARM X-DIFFERENCE.MCR With Channel Calibration Tool
173960.
checks X parallelity of Pipetting Arm
to Deck in functional dependence on
Y-Axis.
Measurement Macro Program.
PIP XY MANUAL ADJUSTMENT.MCR With Channel Calibration Tool
173960.
Shows the linearity and relative
positioning of all channels after
preadjustment, shipping, etc.
Measurement Macro Program.
PIP AUTOADJUSTMENT.MCR With Channel Calibration Tool
173960.
Performs an initial Adjustment and
calibrates the pipetting Arm in X Axis
and its Channels in Y and Z Axis.
Calibration Macro Program.
