105
────────────────────────────────────────────────────
8.3.3 Specific Commands for Output Settings
────────────────────────────────────────────────────
Syntax
:LOAD:SWEep "<name>",<ch>
"<name>" Sweep file name
<ch> Channel number
= 1 to 4 (1 to 2 for the 7075-01)
Example
Transmission
:LOAD:SWE 'SWEEP.SDT',1
Reads the sweep data of the
SWEEP.SDT file into channel 1.
Function
Loads a sweep data file from the
floppy disk, and converts to sweep
data for the specified channel.
Notes
The file name must be surrounded by
single (' ') or double (" ") quotes.
Long file names cannot be used. File
names are case sensitive.
A file name cannot include a
directory. Loading can be done only
from the current directory.
Turn on the sweep setting to enable
the sweep function.
To load the sweep file of an arbitrary
waveform, confirm that the waveform
is present. If the waveform is not
present, the sweep status cannot be
loaded.
When the load finishes normally,
EOSL in Event Status Register 0 is
set.
Errors
(Command error)
When a waveform name is not
surrounded by single (' ') or double
(" ") quotes
(Execution error)
When the specified arbitrary waveform
as sweep waveform is not present.
When the sweep data is not converted
such as RUN active.
:LOAD:SWEep
Load sweep file
