20
────────────────────────────────────────────────────
3.4 Setting the Waveform Parameter
────────────────────────────────────────────────────
NOTE
3.4.3 Offset/Lower Limit Value Settings
Offset
10 V range -10 V to 10 V (resolution 1 mV)
1 V range -1 V to 1 V (resolution 0.1 mV)
0.1 V range -0.1 V to 0.1 V (resolution 0.01 mV)
Lower limit value
10 V range -10 V to upper limit value (resolution 2 mV)
1 V range -1 V to upper limit value (resolution 0.2 mV)
0.1 V range -0.1 V to upper limit value (resolution 0.02 mV)
Jog Dial Entry
The Jog dial can be used to set amplitude or upper limit value.
Setting is inhibited for DC waveforms
Amplitude/offset and upper/lower limit settings are interdependent: a change
to the setting format of one item is automatically applied to the other.
Amplitude --- upper limit
Offset --- lower limit
The output voltage range is the setting at high-impedance load.
The sum of the peak amplitude and the absolute value of the offset is
limited to the set range. Overrange setting is not possible.
The RMS amplitude unit selection is automatically changed to Vp units if
the waveform selection is changed.
Set the offset voltage or lower limit value of the output waveform.
Setting range
Setting unit
V
: Set the voltage value
