Hioki 7075 - Chapter 8 GP-IB;RS-232 C Interface Implementation; Overview

67
────────────────────────────────────────────────────
8.1 Overview
────────────────────────────────────────────────────
SH1
All source handshake functions
AH1
All acceptor handshake functions
T6
Basic talk functions
Serial poll function
The talker cancellation function with MLA (My Listen Address) is provide
d
TE0
Extension talker function is not provided.
L4
Basic listener functions
The listener cancellation function with MTA (My Talk Address) is
provided.
LE0
Extension listener function is not provided.
SR 1
All service request functions
RL 1
All remote/local functions
PP0
Parallel polling is not provided.
DC 1
All device clear functions
DT0
Device trigger functions are not provided.
C1
System controller
C2
IFC transfer, controller, in-charge
C3
REN transmit
C28
Do not transfer interface, message sending and control
Chapter 8
GP-IB/RS-232C Interface
Implementation
8.1 Overview
(1) Compliance and reference standards
The 7075 includes the GP-IB interface as a standard feature.
Compliance standard: IEEE Standard 488.1-1987
Reference standard: IEEE Standard 488.2-1987
(2) Codes used for device-dependent messages
The following are the codes used for device-dependent messages.
ASCII codes are used.
(3) Interface function sub-set
