3.7 Waveform Sweep Settings
────────────────────────────────────────────────────
3.7.10 Setting the End Value
CAUTION
When the Channel ON/OFF key is ON, the preset offset value is output
regardless of whether the RUN/STOP key is on or off. (When the channel is
on, the key lights in red.)
Set the ending value of the item selected in "3.7.7 Selecting the Sweep Items
to Edit." Pressing the
END(Unit)
button or the End Value entry area on the
reversed row enables entry of the ending sweep value.
Frequency
Press the
END(Hz)
button to set the frequency.
The setting method is the same as direct entry in "3.4.1 Frequency/Period
Settings." However, note that even when the period or r/min units have been
used for setting, the display shows equivalent frequency units.
Amplitude
Press the
END(V)
button to set the amplitude.
The setting method is the same as direct entry in "3.4.2 Amplitude/Upper
Limit Settings." However, note that the upper limit value cannot be set and
even when the pp or RMS units have been used for setting, the display
shows equivalent peak units.
Offset
Press the
END(V)
button to set the offset. The setting method is the same as
direct entry in "3.4.3 Offset/Lower Limit Settings." However, note that the
lower limit value cannot be set.
Duty
Press the
END(%)
button to set the duty. The setting method is the same as
direct entry in "3.4.7 Duty Settings."
