Hioki 7075 - Default Chapter; Table of Contents

Contents
Introduction i
Inspection
i
Safety Notes
ii
Notes on Use
iv
Chapter 1 Overview 1
1.1 Product Overview 1
1.2 Features
2
1.3 Names and Functions of Parts
3
1.3.1 Front Panel 3
1.3.2 Rear Panel 4
Chapter 2 Preparation for Use 5
2.1 Installation of the Unit 5
2.2 Connecting the Power Cord
7
2.3 Output Terminal
8
2.4 Basic Operation
9
2.5 Screen Description
10
2.6 Example of Basic Operations
11
2.6.1 Before Operations 11
2.6.2 Output Setting Screen Buttons 11
2.6.3 Simple Waveform Output 12
Chapter 3 Output Setting Screen 15
3.1 Selecting the Output Settings Screen 15
3.2 Selecting the Channel
15
3.3 Selecting the Waveforms
16
3.4 Setting the Waveform Parameter
17
3.4.1 Frequency/Period Settings 17
3.4.2 Amplitude/Upper Limit Value Settings 19
3.4.3 Offset/Lower Limit Value Settings 20
3.4.4 Phase/Delay Settings 22
3.4.5 Range Settings 23
3.4.6 Filter Settings 23
3.4.7 Duty Settings 24
3.4.8 Setting the Number of Loops 24
3.5 Displaying the States of All Channels List 25
3.6 Setting Multiple Channels at the Same Time
26
