10.1 General Specifications
────────────────────────────────────────────────────
Number of channels
4 channels (7075)
2 channels (7075-01)
Output function
Function generator and arbitrary waveform generator (settable for each
channel)
Display
5.7-inch LCD (with touch panel)
Languages
English/ Japanese
External data storage device
3.5-inch floppy disk drive
Capacity
1.44 MB, 1.2 MB, 720 KB formats supported
(1.2 MB format not supported)
Data
MS-DOS format (MS-DOS is a registered trademark of Microsoft
Corporation.)
Recordable data
Output status, sweep data
Interfaces
GP-IB: IEEE 488.1 compliance, IEEE 488.2 reference
RS-232C: Dsub9-pin connector, Transfer speed 19200, 9600, 4800 bps
Temperature and humidity
ranges for operation
10 to 40 (50 to 104 ) , 85%RH or less (with no condensation)
Temperature and humidity
ranges for storage
-10 to 50 (14 to 122 ) , 85%RH or less (with no condensation)
Operating temperature and
humidity for guaranteed accuracy
Period of guaranteed accuracy
23 5 (73 41 ) , 85%RH or less (with no condensation)
*30 minutes after power-on.
1 year
Location for use
Indoors, altitude up to 2000 m (6562 feet)
Dielectric strength
1.5 kV AC/min (Threshold level 25 mA) Power (1 pulse) on cabinet
Power
100/120/200/230 V AC (Voltage fluctuations of 10% from the rated
supply voltage are taken into account.), 50/60 Hz
Maximum rated power
120 VA
Backup battery and lifetime
approx. 3 years
Dimensions
approx. 345 W X 130 H X 286 D mm (13.59" X 5.12" X 11.26")
(excluding protrusion)
