Hioki 7075 - Function Specifications

127
────────────────────────────────────────────────────
9.2 Specifications
────────────────────────────────────────────────────
9.2.2 Function Specifications
Input waveforms
Waveform entry by function input
(14 function types, 7 control word types)
Basic waveform inputs
(Sine, square, triangle, ramp, sin(x)/x, exp, noise and DC
waveforms)
Waveform entry by unlimited curves and straight lines
Editing entered waveforms
Cut, copy, paste, clear
Modifying entered waveforms
Time, amplitude, offset, cycle waveform, phase
Calculations with entered
waveforms
Add, subtract, multiply, normalize, scale, absolute value,
reverse and mirror
Modifying entered waveforms
Magnification, compression, scroll, TIME/DIV display, point
display (time axis) V/DIV display, point display, % display
(time axis)
Save and load created
waveforms
7075 and 7990 format/ 7070 format/ text format (saving
only)
Print created waveforms
Data transfer (RS-232C)
Communications parameters
Baud rate: select from 4800/ 9600/ 19200bps
Parity: non
Data bit: 8bit
Stop bit: select 1 or 2 bit
Xon/Xoff: unused
Hardware flow control: select ON or OFF
Refer to "5.3.2 Setting the RS-232C Interface" for details of connections between the
PC and the unit.
