3.4 Setting the Waveform Parameter
────────────────────────────────────────────────────
NOTE
3.4.1 Frequency/Period Settings
Sine and square
waveforms
0 to 10 MHz (10 mHz)
Pulse, triangle, ramp-up,
ramp-down waveforms
0 to 200 kHz (10 mHz)
Noise, DC
3.4 Setting the Waveform Parameter
Waveform parameters can be set by two methods.
Direct numeric entry
Pressing the button for an item to be set opens the numeric entry window. A
value can then be entered by the tenkeys. Pressing the
CLR
button clears the
entered value.
Changing with the Jog dial
The currently selected (blinking) digit can be changed by turning the dial to
the right to increase, or to the left to decrease. Other digits can be selected
with the cursor keys.
Items can be selected by any of the following methods:
Turn the Shuttle ring to the right or left
Press a cursor key
Press the field of the item to be selected
Depending on the setting format, some settings cannot be performed with the
Jog dial.
Set the frequency of the output waveform.
Setting range The setting range and resolution
Function generator
Arbitrary waveforms
Determined by the sampling clock and waveform size.
0to10MHz(10mHz)
Setting units
Hz
Output and arbitrary waveform sample blocks are set in frequency
units.
r/min
Output and arbitrary waveform sample blocks are set in rpm
(revolutions per minute) units.
s
Output and arbitrary waveform sample blocks are set in period
units.
