Hioki 7075 - Specific Commands for Output Settings

87
────────────────────────────────────────────────────
8.3.3 Specific Commands for Output Settings
────────────────────────────────────────────────────
Syntax
:OSET:AMPLitude <ch>,<voltage>
<ch> Channel number
= 1 to 4 (1 to 2 for the 7075-01)
<voltage> Output voltage value (V)
= 0 to 10.000 V (10 V range)
= 0 to 1.0000 V (1 V range)
= 0 to 100.00 mV (0.1 V range)
Example
Transmission
:OSET:AMPL 1,5
Sets the amplitude voltage of the
output waveform for channel 1 to 5 V.
Syntax
:OSET:AMPLitude? <ch>
<ch> Channel number
= 1 to 4 (1 to 2 for the 7075-01)
Response
syntax
(Header ON)
:OSET:AMPLITUDE <ch>, <voltage>
(Header OFF)
<ch>,<voltage>
Example
Transmission
Response
:OSET:AMPL? 1
(Header ON)
:OSET:AMPLITUDE 1,8.345
(Header OFF)
1,8.34500
Syntax
:OSET:OFFSet <ch>,<voltage>
<ch> Channel number
= 1 to 4 (1 to 2 for the 7075-01)
<voltage> Offset voltage value (V)
Example
Transmission
:OSET:OFFS 1,5
Sets the offset voltage of output
waveform for channel 1 to 5 V.
Function
Sets the amplitude voltage.
Note
The sum of the offset and amplitude is
limited. For details, see Section 3.4.2.
Errors
(Execution error)
When the specified value cannot be
set
When DC is selected as the waveform
type
When sweep is on
Function
Returns the amplitude voltage for the
specified channel as NR2 numerical
data. Units: V
Note
With this query, if any error occurs, no
response message is produced.
Errors
(Execution error)
When DC is selected as the waveform
type
When sweep is on
Function
Sets the offset voltage value.
Note
The sum of the offset and amplitude is
limited. For details, see Section 3.4.2.
Errors
(Execution error)
When the specified value cannot be
set
When sweep is on
8.3.3 Specific Commands for Output Settings
:OSET:AMPLitude
Sets the amplitude voltage.
:OSET:AMPLitude?
Queries the amplitude setting.
:OSET:OFFSet
Sets the offset voltage.
