Hioki 7075 - Page 98

88
────────────────────────────────────────────────────
8.3.3 Specific Commands for Output Settings
────────────────────────────────────────────────────
Syntax
:OSET:OFFSet? <ch>
<ch> Channel number
= 1 to 4 (1 to 2 for the 7075-01)
Response
syntax
(Header ON)
:OSET:OFFSET <ch>,<voltage>
(Header OFF)
<ch>,<voltage>
Example
Transmission
Response
:OSET:OFFS? 1
(Header ON)
:OSET:OFFSET 1,8.34500
(Header OFF)
1,8.34500
Syntax
:OSET:UPLow <ch>,<up>,<low>
<ch> Channel number
= 1 to 4 (1 to 2 for the 7075-01)
<up>
Upper limit of the output voltage (V)
<low>
Lower limit of the output voltage (V)
Example
Transmission
:OSET:UPL 1,5,-2.3
Sets the output voltage range of the
output waveform for channel 1 to from
5 to -2.3.
Syntax
:OSET:UPLow? <ch>
<ch> Channel number
= 1 to 4 (1 to 2 for the 7075-01)
Response
syntax
(Header ON)
:OSET:UPLOW <ch>,<up>,<low>
(Header OFF)
<ch>,<up>,<low>
Example
Transmission
Response
:OSET:UPL? 1
(Header ON)
:OSET:UPLOW 1,2.38000,-2.38000
(Header OFF)
1,2.38000,-2.38000
Function
Returns the offset voltage for the
specified channel as NR2 numerical
data. Units: V
Note
With this query, if any error occurs, no
response message is produced.
Error
(Execution error)
When sweep is on
Function
Sets the upper limit value of the output
voltage.
Note
The difference between the upper limit
value and the lower limit value of the
output voltage is limited.
For details, see Section 3.4.2.
Errors
(Execution error)
When the specified value cannot be
set
When DC is selected as the waveform
type
When sweep is on
Function
Returns the offset voltage for the
specified channel as NR2 numerical
data (<up>, low>). Units: V
Note
With this query, if any error occurs, no
response message is produced.
Errors
(Execution error)
When DC is selected as the waveform
type
When sweep is on
:OSET:OFFSet?
Queries the offset voltage value.
:OSET:UPLow
Sets the upper limit and lower limit of the output voltage.
:OSET:UPLow?
Queries the upper limit and lower limit of the output voltage.
