89
────────────────────────────────────────────────────
8.3.3 Specific Commands for Output Settings
────────────────────────────────────────────────────
Syntax
:OSET:PHASe <ch>,<phase>
<ch> Channel number
= 1 to 4 (1 to 2 for the 7075-01)
<phase> Phase (
)
Example
Transmission
:OSET:PHAS 1,180.00
Sets the phase angle of the output
waveform for channel 1 to 180.
Syntax
:OSET:PHASe? <ch>
<ch> Channel number
= 1 to 4 (1 to 2 for the 7075-01)
Response
syntax
(Header ON)
:OSET:PHAS <ch>,<data>
(Header OFF)
<ch>,<data>
Example
Transmission
Response
:OSET:PHAS? 1
(Header ON)
:OSET:PHASE 1,90.00
(Header OFF)
1,90.00
Syntax
:OSET:DELay <ch>,<data>
<ch> Channel number
= 1 to 4 (1 to 2 for the 7075-01)
<data> Delay (number of points)
=-128000 to 128000
Example
Transmission
:OSET:DEL 1,128000
Sets the delay for channel 1 to
128000.
Function
Sets the phase angle.
Note
The setting range is between -360.00
to 360.00.
Errors
(Execution error)
When the specified value cannot be
set
When DC, noize, or arbitrary
waveform is selected as the waveform
type
When sweep is on
Function
Returns the phase angle for the
specified channel as NR2 numerical
data. Units:
Note
With this query, if any error occurs, no
response message is produced.
Errors
(Execution error)
When DC, noize, or arbitrary
waveform is selected as the waveform
type
When sweep is on
Function
Sets the delay
Errors
(Execution error)
When the specified value cannot be
set
When the specified waveform is not
an arbitrary waveform
When sweep is on
:OSET:PHASe
Sets the phase angle.
:OSET:PHASe?
Queries the phase angle.
:OSET:DELay
Sets the delay.
